Housing material | 304 stainless steel | |
Housing size | L1400*W130*H1000mm(optional) | |
Entrance width | 500-1000mm(optional) | |
Housing thickness | 2.0 mm/3.0mm | |
Net weight | 100Kg/unit | |
Temperature | -10 ℃-50℃ | |
Humidity | ≤90% | |
Motor | Servo motor | |
Normal life-span | 5-8 million times | |
Operation speed | 30-45person/min | |
Working environment | indoor | |
Glass material | Acrylic glass/PC glass | |
Direction | Single direction/Bi-direction | |
Input interface | Dry contact signal or +12V level signal or RS485 communication signal | |
Communication interface | RS485(distance less than 1200m) | |
Main Function | ||
1.Optional card reader:Rfid card ,fingerprint scanner ,face machine ,Bar code, QR code ,card collection ,intercom system ,remote control and so on | ||
2. Access control system ,Ticketing system ,consumption system | ||
3. Standard/customize housing design (ODM/OEM) | ||
5. Optional entrance width(500-1000mm) ,glass door size, operation speed | ||
Applications | ||
Banks and insurance companies ,airports | ||
Government buildings and instituations | ||
Office buildings,head offices,administrative sites | ||
Schools ,universities and colleges | ||
